Note

This technote is not yet published.

A proposal for how an RSP user would make data available to EPO for use in their Zooniverse citizen project.

1 Context¶

1.2 Constraints¶

Zooniverse expects data to be hosted at a public URL it can access dynamically.
Data rights protections and constraints need to be applied.

1.3 Relevant documents¶

LSE-131 Interface Requirements between Data Management and EPO

2 Architecture¶

2.1 User workflow¶

The RSP user henceforth referred to as the (Zooniverse) PI is manipulating data either interactively or though some kind of user batch process to create a Butler run collection that contains the files they wish to make available to their Zooniverse project:

butler = Butler(REPO, run="u/alien/zooniverse-1")
butler.put(myimage, "zooniverse_cutout", dataId=mydataId)

Note that in the case that the user is using a batch processing pipeline for this, the butler put could be done for them.

In the final system, the user will have to grant permission to an EPO service account to retrieve data from their collection.

2.2 EPO service workflow¶

A notional EPO service would have to perform the following tasks

Retrieve the user’s files from the Butler, eg.

butler retrieve-artifacts REPO TARGET_BUCKET --collections=u/alien/zooniverse-1

Create any manifests. metadata etc required by zooniverse
Apply any data rights controls or quarantine outgoing data for approval
Maintain an index of PI projects and their run collections that it can use to batch retrieve or poll user collections for data

2.3 Image conversion¶

On the assumption that Zooniverse wants png or jpeg or some other kind of non-native representation of the pixel, a Butler dataset type can be defined with the appropriate formatter. The butler Formatter would have to be written to convert the Python object to the appropriate on-disk format (e.g. PNG).

3 Separation of Concerns¶

The RSP system ensures the PI is authenticated and is able to query and retrieve their data of interest, manipulate it (if desired) and store it into the RSP/DF butler registry. It is also responsible for supplying the authorisation model that allows the user to permit an EPO service account to read their data.
The EPO system is responsible for the code that retrieves the user’s data, (optionally but recommended) validate it for exfiltration according to applicable policies, and publish it in an http-accessible location from where it can be retrieved without authentication.
Science Pipelines is responsible for providing any butler-specific configuration (such as a PNG formatter) required to meet the DM-EPO interface specifications.
If there was a python package or other client that would allow the PI to manage aspects of their zooniverse project(s) - eg project creation, deletion, it can be installed at the RSP so that it is available from the notebook aspect environment.

4 Notes¶

I think we’d all feel better if zooniverse could access an authenticated web server
There is lack of clarity on whether u/user/ collections are permanent, attached to DR-specific registries, or unguaranteed
A tutorial notebook or helper class could be made available to walk PIs through the process. The notebook could be added to the mobu harness to alert to any interface drifts.
When RSP’s semaphore service is extended to deal with per-user notification, we could provide an API that allows EPO to send per-user notifications informing them of relevant status, such as that their files have been retrieved and can be safely removed.
If there is any specific metadata that zooniverse needs that is dropped by the butler retrieve-artifacts, DM can work with EPO to advice on how to obtain it so it can be included with the manifest.

DMTN-207: Architecture for the DM-to-EPO data export for Citizen Science projects
